John Deere 8R 410

Specifications, maintenance, parts and compatibility reference.

Specification set: United States - Current 8R wheel tractor - cab, MFWD/ILS options Current Deere US 8R wheel lineup is 250-410. Historical 8R 230 remains in service guides but is intentionally not marked current.

Machine Configuration

Operator stationCab

Engine

Engine manufacturerJohn Deere

Engine displacement9 L

Engine modelJD9

Engine familyVJDXL09.0333

Engine horsepower410 hp

Cylinders6

Maximum engine power443 hp

AspirationDual turbochargers - variable-geometry plus fixed-geometry in series

Rated engine speed2100 rpm

Emissions certificationFinal Tier 4

Seeding Hydraulic Intelligent Power Management boost35 hp

Transmission

Transmissione23 PowerShift 40K

Transmission optionse23 50K; AutoPowr/IVT 40K or 50K; 16-speed PowerShift on select lower-horsepower 8R models; EVT availability varies by model

Maximum wheel-tractor transport speed31 mph

PTO

PTO power310 hp

Hydraulics

Standard hydraulic pump output60 gpm

Optional hydraulic pump output84 gpm

Rear 3-point hitch lift capacity20000 lb

Optional front hitch lift capacity8240 lb

Compatible parts & kits

This source-backed list can include maintenance parts, mounting hardware and accessory kits. Serial-number and machine-configuration restrictions may still apply, so review each part page before ordering or installing.

HXE135862Air Dryer Filter ElementAir Dryer Filters →RE597838CTIS Onboarding Air Coalescing FilterAir Dryer Filters →RE596317Primary Engine Air FilterAir Filters →RE596318Secondary Engine Air FilterAir Filters →RE284091Cab Fresh Air FilterCabin Air Filters →RE593819Cab Recirculation Air FilterCabin Air Filters →DZ114640DEF Supply Module FilterDEF Filters →DZ124403DEF Inline FilterDEF Filters →RE509672Engine Oil FilterEngine Oil Filters →AT365869Fuel Water Separator FilterFuel / Water Separators →DZ110558Secondary Fuel Filter Element - Current SerialFuel Filters →DZ112918Secondary Fuel Filter Element - Early SerialFuel Filters →RE539465Primary Fuel Filter ElementFuel Filters →RE269061Pilot Valve / SCV Filter - Early SerialHydraulic Filters →RE596661Hydraulic Oil Filter ElementHydraulic Filters →TA21586Pilot Valve / SCV Filter - Current SerialHydraulic Filters →H216169Vent FilterVent Filters →

Sources

John Deere · official sourceJohn Deere US current 8 Series 250-410 product family

John Deere · official sourceJohn Deere official 8 Series tractor specifications
