Tractor reference
Kubota M6L-111
Specifications, maintenance, parts and compatibility reference.
Specification set: United States - M6L-111 low-profile orchard tractor 2026 low-profile model; published speed range is retained as a range instead of being reduced to a single transport-speed claim.
Machine Configuration
Operator stationOpen station / ROPS
Specialty tractor classLow-Profile
Engine
Engine manufacturerKubota
Engine typeKubota V3800-TIEF4 CRS direct-injection 4-cylinder turbocharged intercooled diesel
Cylinders4
Displacement230 cu in
Gross engine power114.1 hp
Transmission
Transmission speedsF32/R32 fully synchronized; F48/R48 with creep
Published traveling speed range0.86–18.56 mph
Maximum traveling speed18.6 mph
PTO
PTO power95 hp
Dimensions & Weight
Published height reference89.4 in ROPS height
Overall width83.5 in
Overall length163.2 in
Crop / ground clearance18.5 in
Wheelbase95.9 in
Tractor weight7077 lb
Sources
Kubota · official sourceKubota USA 2026 Full Product Line - Utility/Specialty Ag Tractors
