Tractor reference
Kubota M5-091
Specifications, maintenance, parts and compatibility reference.
Specification set: United States - M5-091HF 2WD open station, F8/R8 Current US M5 variant confirmed by Kubota USA 2026 product material and active 2026 sales offer; specification values use the 2026 Full Product Line table.
Machine Configuration
Operator stationOpen Station
Drive type2WD
Engine
Engine manufacturerKubota
Engine modelV3800CR-TIER4
Engine type4-cylinder turbocharged Common Rail direct-injection diesel with intercooler, DPF, DOC and SCR
Cylinders4
Displacement230 cu in
Rated engine power92.5 hp
Transmission
Standard transmissionF8/R8
Maximum wheel-tractor transport speed17.7 mph
Shuttle shiftElectro-hydraulic shuttle
Main clutchMultiple wet disc
PTO
Rated PTO power76 hp
PTO actuationLive-independent PTO, electro-hydraulic clutch with brake
Rear PTO540 rpm; 540E optional
Hydraulics
Rated flow at remote outlets15.7 gpm
Rear hitch categoryCategory II with telescopic lower-link ends and stabilizers
3-point control systemPosition, draft (top-link sensing) and mixed control
Rear remote valves2 standard (maximum 3)
Rear 3-point lift capacity at 24 in.4630 lb
Dimensions & Weight
Overall length156.5 in
Wheelbase90 in
Overall height98.9 in
Overall width77.2 in
Base machine weight5732 lb
Capacities
Fuel tank capacity27.7 US gal
Steering & Brakes
SteeringHydrostatic power steering
Brake typeHydraulic wet disc
Compatible parts & kits
This source-backed list can include maintenance parts, mounting hardware and accessory kits. Serial-number and machine-configuration restrictions may still apply, so review each part page before ordering or installing.
Compatible attachments
Attachment compatibility is stored separately from service parts. Configuration requirements below come from the cited compatibility source and can vary by driveline or tractor version.
Front loaderKubota LA1854Kubota USA 2026 Full Product Line explicitly lists LA1854 as the compatible front loader for the current M5 Series.Front loader details: Height/power boom-cylinder fulcrum positions; standard quick coupler, optional Euro-type quick coupler and optional single-lever hydraulic hose quick coupler.
Lift capacity at pivot pin/max height: 3,990 lb height-position / 4,144 lb power-positionLift height: Maximum pivot-pin lift height: 145.7 in height-position / 131.9 in power-position
Sources
Kubota · official sourceKubota USA 2026 Full Product Line - M5 compatible front loader LA1854
