Tractor reference
Kubota M7-154
Specifications, maintenance, parts and compatibility reference.
Reference set: United States · M7-154 Deluxe, 4WD cab, 30F/15R semi-powershift · Current Current US M7 Generation 4 grade confirmed by Kubota USA 2026 Full Product Line.
Reference versions: United States · M7-154 Deluxe, 4WD cab, 30F/15R semi-powershift · Current · United States · M7-154 Premium, 4WD cab, 30F/15R semi-powershift · Current · United States · M7-154 Premium KVT, 4WD cab, Kubota Variable Transmission · Current
Current is selected by default. Historical, manual-specific and market-unspecified contexts stay separate so their parts and service data are not presented as current-US fitment.
Current is selected by default. Historical, manual-specific and market-unspecified contexts stay separate so their parts and service data are not presented as current-US fitment.
Machine Configuration
Operator stationDeluxe Cab
Engine
Engine manufacturerKubota
Engine familyV6108-CR Tier 4 Final
Engine typeDirect injection, intercooled turbocharged, water-cooled 4-cycle diesel
Cylinders4
Displacement374 cu in
Maximum power with EPM20 hp
Gross engine power148 hp
Rated engine speed2100 rpm
Transmission
Standard transmissionF30/R15; F54/R27 with optional creep
Transmission typeSemi-Powershift
Main gear shift6-speed Powershift
Shuttle shiftElectro-hydraulic shuttle
Range gear shift5-speed synchronized (GST)
Main clutchHydraulic multi-plate wet disc
PTO
PTO power120 hp
PTO configuration540 / 540E / 1000 / 1000E rpm
Front PTO1000 rpm optional front PTO
Hydraulics
Hydraulic control systemElectronic draft control / lower-link sensing
Hydraulic systemClosed center load sensing (CCLS)
Hydraulic pump rated output29 gpm
Standard rear remote valves3 standard, up to 4 mechanical valves
3-point hitchCategory 3 / 3N telescopic lower link
3-point hitch lift capacity at 24 in. behind lift point11797 lb
Dimensions & Weight
Overall height121.7 in
Overall length188 in
Overall width98.4 or 110 in depending rear axle configuration
Standard 4WD wheelbase107 in
Tractor weight14456 lb
Capacities
Fuel tank capacity87 US gal
DEF tank capacity10 US gal
Compatible parts & kits
Parts shown here are limited to the selected reference context plus generic machine-level fitment. Configuration-specific fitment, evidence confidence and the direct fitment source are shown under each part when available.
6A671-75090Cabin Air Recirculation FilterApplies to: Current US M7-154S grade-specific service-filter reference; confirm tractor serial number before ordering.Evidence: High-confidence source-backed fitment · Messicks Kubota M7-154S parts catalog - M7 Gen 4 service filters →Cabin Air Filters →
3J037-31510Engine Air Filter Element 2Applies to: Current US M7-154S grade-specific service-filter reference; confirm tractor serial number before ordering.Evidence: High-confidence source-backed fitment · Messicks Kubota M7-154S parts catalog - M7 Gen 4 service filters →Engine Air Filters →
1G311-43380Fuel Filter Separator ElementApplies to: Current US M7-154S grade-specific service-filter reference; confirm tractor serial number before ordering.Evidence: High-confidence source-backed fitment · Messicks Kubota M7-154S parts catalog - M7 Gen 4 service filters →Fuel / Water Separators →
1J520-43060Fuel Filter Element AssemblyApplies to: Current US M7-154S grade-specific service-filter reference; confirm tractor serial number before ordering.Evidence: High-confidence source-backed fitment · Messicks Kubota M7-154S parts catalog - M7 Gen 4 service filters →Fuel Filters →
HH1J0-43172Fuel Filter CartridgeApplies to: Current US M7-154S grade-specific service-filter reference; confirm tractor serial number before ordering.Evidence: High-confidence source-backed fitment · Messicks Kubota M7-154S parts catalog - M7 Gen 4 service filters →Fuel Filters →
Documented attachment fitment
Attachment fitment is stored separately from the specification/parts version selector. Multiple cited records for the same attachment are grouped below rather than shown as duplicate attachments. A listed attachment may still require a specific axle, driveline, transmission or tractor configuration.
Front loaderKubota LM2606Fitment note: LM2606 is current across available M7 Gen 4 grades; mechanical joystick on Deluxe and electronic joystick on Premium/Premium KVT. Confirm tractor/loader mounting configuration before installation.Front loader details: Z-bar linkage with mechanical self-leveling; mechanical joystick on Deluxe, electronic joystick on Premium/Premium KVT; third function, single-lever hydraulic quick coupler and KSR accumulator standardFitment source: Kubota USA 2026 Full Product Line - current M7 Gen 4 LM2606 mapping →
5,776 lb at bucket pivot pin at maximum height; 5,765 lb at 800 mm forward at maximum heightLift height: 167 in maximum lift height at bucket pivot pin; 156 in at bucket-under-level
Sources
Kubota · official sourceKubota USA 2026 Full Product Line - current M7 Gen 4 LM2606 mapping
Messicks · supplier referenceMessicks Kubota M7-154S parts catalog - M7 Gen 4 service filters
